CPU AnnapurnaLabs, an Amazon company Alpine AL524, 4-core, 2.0GHz
CPU Architecture 64-bit ARM
Floating Point Unit
Encryption Engine
System Memory 4 GB SODIMM DDR4
Maximum Memory 16 GB (1 x 16 GB)
Memory Slot 1 x SODIMM DDR4
Support ECC memory
Flash Memory 512 MB (Dual boot OS protection)
Drive Bay 6 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility 3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable
SSD Cache Acceleration Support
2.5 Gigabit Ethernet Port (2.5G/1G/100M) 2(2.5G/1G/100M)
10 Gigabit Ethernet Port 2 x 10GbE SFP+
Wake on LAN (WOL)
Jumbo Frame
PCIe Slot 1
Slot 1: PCIe Gen 3 x4
Card dimensions for PCIe slot：190 x 68.9x 18.76 mm / 7.48 x 2.71 x 0.74 inches.
USB 3.2 Gen 1 port 2
Form Factor Tower
LED Indicators Power, Status, LAN, USB, HDD1-6
Buttons Power, Reset, USB Auto Copy
Dimensions (HxWxD) 226.5 × 235 × 165 mm
Weight (Net) 2.5 kg
Weight (Gross) 4.96 kg
Operating Temperature 0 - 40 °C (32°F - 104°F)
Storage Temperature -20 - 70°C (-4°F - 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 120W
adapter (12VDC), 100-240VAC
Fan 2 x 90mm, 12VDC
System Warning Buzzer
Kensington Security Slot
Standard Warranty 2
